196 Rockwell Automation Publication 750-IN001O-EN-P - October 2014

Chapter 4 Power Wiring

Table 19 - 600V, 50 Hz Input - Code P3 Thermal Magnetic Circuit Breaker Options

Table 20 - 600V, 50 Hz Input - Code P5 Molded Case Disconnect Switch Options (Floor Mount Frame

8 Only)

Hp Amps Duty Line Side Terminal

Lugs

Terminal Size Recommended Torque

250 272 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

300 295 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

295 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

350 329 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

355 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

355 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

355 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

400 395 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

395 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

395 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

450 425 Heavy 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

435 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

435 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

500 460 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

460 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

510 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

510 Normal 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)

550 545 Light 140G-M-TLA23 (2) 250…500 MCM kit of 3 31 N•m (274 lb•in)
