Allen-Bradley PowerFlex 20-750-S1 User Manual

206 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 4 Power Wiring
Figure 110 - Option P3 or P5 Disconnect and Option P12 Output Contactor
(Floor Mount Frame 8 Only)
No. Name Description
➊ R/L1, S/L2, T/L3 Three-phase input power connection.
➋ PE Three-phase input ground.
➌ PE Three-phase motor ground.
➍ U/T1, V/T2, W/T3 Motor connection.
➍
➋
➌
➊
Drive
Motor
P3 or P5
P12
