208 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 4 Power Wiring
Table 25 - 600V, 50 Hz Input - Code P12 Output Contactor Options (Floor Mount Frame 8 Only)
Table 26 - 690V, 60 Hz Input - Code P12 Output Contactor Options (Floor Mount Frame 8 Only)
Hp Amps Duty Contactor Cat. No. Recommended Torque
250 272 Heavy 100-D420ED11 17 N•m (150 lb•in)
300 295 Heavy 100-D420ED11 17 N•m (150 lb•in)
295 Normal 100-D420ED11 17 N•m (150 lb•in)
350 329 Heavy 100-D420ED11 17 N•m (150 lb•in)
355 Heavy 100-D420ED11 17 N•m (150 lb•in)
355 Light 100-D420ED11 17 N•m (150 lb•in)
355 Normal 100-D420ED11 17 N•m (150 lb•in)
400 395 Heavy 100-D420ED11 17 N•m (150 lb•in)
395 Light 100-D420ED11 17 N•m (150 lb•in)
395 Normal 100-D420ED11 17 N•m (150 lb•in)
450 425 Heavy 100-D630ED11 68 N•m (600 lb•in)
435 Light 100-D630ED11 68 N•m (600 lb•in)
435 Normal 100-D630ED11 68 N•m (600 lb•in)
500 460 Light 100-D630ED11 68 N•m (600 lb•in)
460 Normal 100-D630ED11 68 N•m (600 lb•in)
510 Light 100-D630ED11 68 N•m (600 lb•in)
510 Normal 100-D630ED11 68 N•m (600 lb•in)
550 545 Light 100-D630ED11 68 N•m (600 lb•in)
kW Amps Duty Contactor Cat. No. Recommended Torque
200 215 Heavy 100-D420EA11 17 N•m (150 lb•in)
250 265 Heavy 100-D420EA11 17 N•m (150 lb•in)
265 Normal 100-D420EA11 17 N•m (150 lb•in)
300 308 Heavy 100-D420EA11 17 N•m (150 lb•in)
315 330 Light 100-D420EA11 17 N•m (150 lb•in)
330 Normal 100-D420EA11 17 N•m (150 lb•in)
355 370 Heavy 100-D420EA11 17 N•m (150 lb•in)
370 Light 100-D420EA11 17 N•m (150 lb•in)
370 Normal 100-D420EA11 17 N•m (150 lb•in)
375 375 Heavy 100-D420EA11 17 N•m (150 lb•in)
400 410 Light 100-D420EA11 17 N•m (150 lb•in)
413 Heavy 100-D420EA11 17 N•m (150 lb•in)
415 Normal 100-D420EA11 17 N•m (150 lb•in)
450 460 Light 100-D630EA11 68 N•m (600 lb•in)
460 Normal 100-D630EA11 68 N•m (600 lb•in)
500 500 Light 100-D630EA11 68 N•m (600 lb•in)
500 Normal 100-D630EA11 68 N•m (600 lb•in)
530 530 Light 100-D860EA11 68 N•m (600 lb•in)
