Allen-Bradley PowerFlex 20-750-S1 User Manual

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 83
Lift and Mount the Drive Chapter 3
Figure 44 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 8
Enclosure Code B - 600 mm Deep Drive with Cabinet Options Bay.
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
2453
(96.6)
1200
(47.2)
2300
(90.6)
68
(2.7)
76
(3.0)
180
(7.1)
127
(5.0)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
ø18.0
(0.71)
542
(21.3)
43
(1.7)
600
(23.6)
240
(9.4)
➊
➊
➋
➊
➊
➋
➎
➍
1808
(71.2)
500
(19.7)
440
(17.3)
205
(8.1)
141
(5.6)
127
(5.0)
76
(3.0)
440
(17.3)
440
(17.3)
1464
(57.6)
➌
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
➌ Optional exhaust hood.
➍ Optional HIM.
➎ Recommended four-hole anchoring.
BOTTOM
TOP
BOTTOM
