Allen-Bradley PowerFlex 20-750-S1 User Manual

98 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 59 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
Enclosure Code B with P14 - 600 mm Deep Drive with Cabinet Options Bay.
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
ø18.0
(0.71)
542
(21.3)
43
(1.7)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
1269
(50.0)
1500
(59.1)
1731
(68.1)
500
(19.7)
500
(19.7)
440
(17.3)
141
(5.6)
127
(5.0)
76
(3.0)
76
(3.0)
205
(8.1)
➊➊
➊
➋➋
