ASSEMBLY INSTRUCTIONS
6
6. Lower decorative cap (D) over adjustment dial
(G) and secure with finial (H).
In order to change the motion sensor settings
you must unscrew finial (H) and remove
decorative cap (D) to access the motion
sensor adjustment dial (G).
6
D
H
G
OPERATING INSTRUCTIONS
Selecting a Location:
• When installed at a height of 6.5 ft., at 68ºF, the light will provide a maximum detection distance
of 40 ft. The sensitivity will be higher at cooler temperatures. You may want to make
adjustments again when the season changes.
• The detection range coverage is approximately 120 degrees.
6.5 ft.
40 ft.
120˚
Top View
