ASSEMBLY INSTRUCTIONS
4
Machine
Screw
AA
2. Secure fixture base (C) to post (not included)
with machine screws (AA).
1B
1A
x 3AA
BB
C
Lowes.com/allenandroth
Hardware Used
Wire
Connector
x 3BB
Hardware Used
2
Post
(Not Included)
CONNECT HOT, BLACK OR RED OUTLET SUPPLY WIRE TO: CONNECT NEUTRAL, WHITE OUTLET SUPPLY WIRE TO:
Black White
* Parallel Cord (round and smooth) * Parallel Cord (square and ridged)
Clear, Brown, Gold or Black without Tracer (colored stripes) Clear, Brown, Gold or Black with Tracer (colored stripes)
Insulated Wire (not green) with Copper Metal Conductor Insulated Wire (not green) with Silver Metal Conductor
1. Supply wire connection guide: Make wire connections, securing with wire connectors (AA), following
the reference chart listed below.
*NOTE:
When parallel wire (SPT I & SPT II) is used,
the neutral wire is square shaped and ridged
and the hot wire will be round in shape and
smooth.
To Next Page
