Allen + Roth LWS3FS - Page 2

3
4
PACKAGE CONTENT
PART DESCRIPTION QUANTITY
A Left Side Frame 1
B Right Side Frame 1
C Left Side Panel 1
D Right Side Panel 1
E Top Panel 1
F Bottom Panel 1
G Back Panel 1
H Panel Shelf 2
PART DESCRIPTION QUANTITY
I Metal Bar 2
J Drawer Front 1
K Drawer Left 1
L Drawer Right 1
M Drawer Back 1
N Drawer Bottom 1
O Drawer Stretcher 1
A
F
C
D
I
J
N
K
E
H
G
B
L
M
O
HARDWARE CONTENTS
(shown not actual size)
Cam Bolt
Qty. 22
Nut
Qty. 1
Handle
Qty. 1
Tipping Restraint
Hardware
Qty. 1 set
AA
FF
II
MM
BB
GG
JJ
DDCC
HHEE
KK LL
Large Cam Lock
Qty. 16
Touch-up Pen
Qty. 1
5/32” x 12mm Bolt
Qty. 2
M4 x 32mm Screw
Qty. 18
Wood Dowel
Qty. 14
Small Cam Lock
Qty. 6
1/4”x 10mm Bolt
Qty. 5
Allen Wrench
Qty. 1
Open Wrench
Qty. 1
