AllFitHD AF-4222LS - Page 5

22
27
19
21
20
24
3
22
2
18
19
Attach Hitch Mount Tubes (19) to Sweeper Assembly and tighten hardware.
DO NOT OVERTIGHTEN.
Attach Handle (3) to Height Adjustment (2) and tighten hardware.
Insert Hitch Tubes (18) into Hitch Mount Tubes (19) and snap into position.
4
Assembly Instructions
1
3
2
