AllFitHD AF-4222LS - Page 6

25
21
21
22
25
21
22
SHOWN INSTALLED
4
H
25
21
21
22
DETAIL H
SCALE 1 : 3
DETAIL P
SCALE 1 : 5
Install hardware through front two holes of Hitch Tubes as shown.
DO NOT TIGHTEN
AT THIS TIME.
Hold Adjustment Lever (4) in position and install third bolt through Lever as shown.
Pin Adjustment Lever to Handle with Hair Pin (26).
DO NOT TIGHTEN
AT THIS TIME.
5
Assembly Instructions
4
5
