Bluetooth® – Known Successful Methods
There are 5 scenarios to correctly implement Bluetooth®. These are:
1. RS340+CM301 to a Bluetooth® adapter connected to a scale head.
2. RS340+CM301 to a Bluetooth® adapter connected to a Computer Serial Port.
3. RS340+CM301 to a Bluetooth® enabled computer.
4. RS340+CM301 (With Hardware ON/OFF switch
*
) to a Bluetooth® enabled
PDA (Palm Top Computer/Portable Data Assistant)
5. RS340+ CM301 to a dedicated Bluetooth® device, such as printer.
These options are discussed in further detail below.
1. RS340+CM301 to a Bluetooth® adapter connected to a scale head.
This scenario requires that a process called
“Pairing” be undertaken. This requires the
Allflex Configurator© software to configure
the reader to correctly link to the Bluetooth®
module connected to the scale head. Most
Allflex offices pre-match readers to
Bluetooth® adapters prior to dispatch.
If your RS340 and Bluetooth® adapter have
not been set up for you, or have lost their
pairing, Allflex Configurator© Software will
be required to complete the Pairing Process.
Depending upon the country, Allflex Configurator© Software will either be supplied
on a specific Configurator© CD supplied with the reader, or included on other CD’s
such as NLIS Link in Australia. Install the Configurator© Software. The scale head
serial port must supply power on pin 9.
*
Please contact your Allflex reseller for this specific Bluetooth module
Stock Weigh
Electronic
Scale Head
Bluetooth Module
connected to serial
p
ort
