Green READ Button Applies power and causes activation signal to be emitted
for reading transponder
Data/Power Cable Conveys external power to Reader and serial data to and
from Reader
DB9 Connector w/
DC Power Jack
Connects serial data to PC, scale head, or data logger
RS232 port. Accepts 12 VDC input as Reader power
source
Fiberglass Tube Rugged, watertight enclosure
Screw-on Endcap Provides access to battery compartment
Handle Grip Rubber anti-slip gripping surface
Cable Connector Electrical interface for attaching Data/Power Cable
Rubber End Cap Protect the reader from shocks
