Part
No. F238
000R0
Septemb
er 1999
B003C
Pr
eliminary Ser
v
ice
W
asher
-Extractor
Cabinet Hardmount
HC18
SC18
UC18
HC25
SC25
UC25
HC35
SC27
UC27
HC50
SC35
UC35
SC50
UC50
2
Table of Contents
Default Chapter
2
Table of Contents
2
Section 1 - Safety Information
3
Locating an Authorized Servicer
4
Section 2 - Introduction
5
Customer Service
5
Nameplate Location
5
Model Identification
6
Model Familiarization
7
How Your Washer-Extractor Works
8
Section 3 - Troubleshooting
9
Machine Won't Start
9
Machine Does Not Operate at Wash Speed
9
Motor Runs, but Cylinder Rotates Slowly, or Not at All
9
Wash Motor Runs Continuously in One Direction
10
Motor Does Not Operate at Spin Speed
10
Motor Momentarily Starts on and off in Spin
10
Machine will Not Fill with Water
10
Machine will Not Drain
11
Machine will Not Hold Water
11
Door Won't Open
11
Water Level too High
11
Water Level too Low
11
Door Leaks
11
Excessive Vibration And/Or Noise During Spin
12
Excessive Cycle Time
12
Section 4 - Service Procedures
13
Cabinet Top
13
Control Module Box Cover
13
Coin Drop
13
Indicator Lights
14
Graphic Panel Overlay
15
Timer and Selector Switch Bracket
15
Pressure Switch
16
Door Lock PC Board / Capacitor
17
Timer Delay Relay
18
Flange Relay
18
Contactors
19
Overload Protector
20
Control Transformer
20
Mechanical Interlock
21
Solid State/Start Switch
21
Water Valves
22
Siphon Break
23
Dispenser
24
Belt
25
Motor
25
Motor Capacitors
26
Outer Front Panel
26
Loading Door
27
Door Lock Assembly
28
Cylinder Assembly
29
Trunnion Assembly
29
Bearings and Seals
