Specifications - 895 & 895TSL
Model number: 895
Mounting height: 50.0 (nominal)
Typical range: 46.0 to 54.0
Description Bucket Lift TSL Bucket
Bore 3.00 3.50 3.00
Rod 1.75 2.00 1.75
Stroke 26.50 32.50 24.75
A - Maximum lift height (full height): 172" (14.3')
B - Clearance with bucket dumped (full height): 140" (11.7')
C - Reach at full height: 30"
D - Maximum dump angle (full height): 40°
D - TSL max dump angle at ground: 65°
D1 - TSL dump angle at ground: 91°
F - Bucket rollback angle ground: 21°
F1 - TSL bucket rollback angle: 34°
G - Digging depth: 6.6"
H - Overall height in carry position: 89" (7.4')
R - Rollback angle at full height: 108°
Estimated breakout force: 7610 lbs
Estimated lift capacity: 4415 lbs
Notes:
1 - Estimated values assume 2500 psi lift cylinder pressure
2 - Breakout force estimated as per ASAE S301.2 - 4.1.2 (net payload applied at cutting edge)
3 - Lift capacity estimated as per ASAE S301.2 - 4.1.1
4 - Main pivot pin: 1.50 All other pins: 1.25
