Specifications - 95 & 195 Loader
Model number: 95
Mounting height: 23" (nominal)
Typical range: 20" - 26"
Description Bucket Lift
Bore 1.50" 1.50"
Rod 1.00" 1.00"
Stroke 13.25" 14.50"
Length 34.75" 37.00"
Length 21.50" 22.50
A - Maximum lift height to pivot point (full height): 78"
B - Clearance with bucket dumped: 61"
C - Reach at maximum height: 18"
D - Maximum dump angle: 45°
F - Bucket rollback angle: 14°
G - Digging depth: 3.9"
H - Overall height in carry position: 48" (12')
R - Rollback angle at full height: 96°
Estimated breakout force: 850 lbs
Estimated lift capacity: 525 lbs
Notes:
1 - Estimated values assume 1800 psi lift cylinder pressure
2 - Breakout force estimated as per ASAE S301.3 - 5.1.6 (net payloud applied at 31.5" forward of
bucket pivot)
3 - Lift capacity estimated a per ASAE S301.3 - 5.1.1 (net payload applied at bucket pivot point pin)
4 - Main pivot pins: 1.00" dia.
5 - All other pins 0.75" dia
