Specifications - 95 & 195 Loader
Model number: 195
Mounting height: 26" (nominal)
Typical range: 23" - 29"
Description Bucket Lift
Bore 2.00" 2.00"
Rod 1.25" 1.25"
Stroke 13.38" 15.00"
Extended Length 37.00" 40.00"
Retracted Length 23.63" 25.00"
A - Maximum lift height to pivot point (full height): 90"
B - Clearance with bucket dumped: 74"
C - Reach at maximum height: 15"
D - Maximum dump angle: 40°
F - Bucket rollback angle: 19°
G - Digging depth: 3.3"
H - Overall height in carry position: 51" (12')
R - Rollback angle at full height: 104°
Estimated breakout force: 1600 lbs
Estimated lift capacity: 1150 lbs
Notes:
1 - Estimated values assume 2000 psi lift cylinder pressure
2 - Breakout force estimated as per ASAE S301.3 - 5.1.6 (net payload applied at 31.5" forward of
bucket pivot)
3 - Lift capacity estimated as per ASAE S301.3 - 5.1.1 (net payload applied at bucket pivot point pin)
4 - Main pivot pins: 1.00" dia.
5 - All other pins 0.75" dia
