Allison Transmission 4700 SP User Manual

LISTOFWARNINGS(cont'd)
Thismanualcontainsthefollowingwarnings—
ITISYOURRESPONSIBILITYTOBEFAMILIARWITHALLOFTHEM.
•Thisinputfunctioninvolvestheuseofcomplexalgorithmsin
thecontrollogic.Ifthefunctionisenabledinthecalibration
butthecontrolcircuitforthefunctionisnotinstalled,thereis
apotentialriskforoneormoresystemfailuremodeswhich
couldresultinundesirabletransmissionoperation.Therefore,
theactivationcircuitforthisfunctionMUSTBEproperly
integratedinthevehicleinwhichitisinstalled.Ifthefunction
willnotbeusedinthenalvehicle,itMUSTNOTbeorderedin
thecalibration.Forspecicinstallations,thevehiclemaybe
operatedpriortofullintegrationofthefunctionintothevehicle
wiring.Forexample,abarechassistransportedtoabody
builderwherethefunctionwillbewiredintothecompleted
vehicle.Inthesecases,ifthefunctionisactivatedinthe
calibration,thespecicwiresrelatedtothefunctionmustbe
electricallyisolated,completelyandindividually.Untilproperly
integratedintothenalvehiclewiring,thechassisbuildermust
protectthewiressuchthattheydonotmakeelectricalcontact
withthefollowing:
•eachother,ifthefunctioninvolvesmorethanonewire
•anyothertransmissionwiring
•anyothervehiclewires
•anypartofthevehicleorchassis
•Thisschematicshowstheintendeduseofthespecied
controlsfeaturewhichhasbeenvalidatedintheconguration
shown.Anymiswiringoruseofthisfeaturewhichdiffersfrom
thatshowncouldresultindamagetoequipmentorproperty,
personalinjury,orlossoflife.AllisonTransmissionisnotliable
fortheconsequencesassociatedwithmiswiringorunintended
useofthesefeatures.
12

Allison Transmission 4700 SP Specifications

General

Brand	Allison Transmission
Model	4700 SP
Category	Controller
Language	English
