ASSEMBLY PADS
(BOTH SIDES)
TO RETARDER
ACCUMULATOR
OIL FILL TUBE AND
DIPSTICK
(AVAILABLE ON
BOTH SIDES
)
OUTPUT
RETARDER
TORQUE CONVERTER
WITH LOCKUP CLUTCH
AND TORSIONAL DAMPER
BREATHER
MAIN-PRESSURE TAP
NOTE: Inch series threads
FEEDTHROUGH
HARNESS
CONNECTOR
RETARDER
VALVE BODY
CONNECTOR
OUTPUT
SPEED
SENSOR
ASSEMBLY PADS
MAIN-PRESSURE TAP
NOTE: Inch Series Threads
BREATHER
COOLER PORTS
NOTE: Inch Series Threads
LEFT-REAR VIEW
LEFT-FRONT VIEW
V07307.03.00
TACHOGRAPH PROVISION
NOTE: Metric Series Threads
Figure 3. 3000/3500 EVS With Retarder
(WTEC III Controls)
11
