Allison Transmission Emergency Vehicle Series User Manual

MOUNTING
PAD
MOUNTING PAD
PTO PROVISION
PTO
PROVISION
C6 ADAPTER
HOUSING
RETARDER
OUTPUT
FLANGE
BREATHER
LEFT-REAR VIEW
RIGHT-REAR VIEW
V08619.01.00
TURBINE
SPEED
SENSOR
MOUNTING
PAD
C6 ADAPTER
HOUSING
INPUT
SPEED
SENSOR
NAMEPLATE
FILL TUBE
PTO PROVISION
(TOP RIGHT
POSITION)
OUTPUT
SPEED SENSOR
FEEDTHROUGH
HARNESS CONNECTOR
Figure 8. 4700/4800 EVS With PTO And Retarder
(Allison 4
th
Generation Controls)
16
