Allison Transmission Motorhome Series Owner's Manual

6
OIL LEVEL SENSOR
P2 MODULE
P1 MODULE
CONVERTER MODULE • TURBINE • PUMP • LOCKUP CLUTCH/DAMPER • STATOR
CONVERTER HOUSING MODULE • CONVERTER HOUSING
ROTATING CLUTCH MODULE • C1 CLUTCH • C2 CLUTCH • TURBINE SHAFT
CONTROL MODULE • ELECTRO-HYDRAULIC CONTROLS
MAIN SHAFT MODULE • MAIN SHAFT • P2 SUN • P3 SUN
MAIN HOUSING MODULE • MAIN HOUSING • C3 CLUTCH • C4 CLUTCH • C5 CLUTCH
FRONT SUPPORT/OIL PUMP MODULE • FRONT SUPPORT • OIL PUMP
REAR COVER MODULE • OUTPUT SHAFT • P3 • C5 PISTON
V03348.02
Typical 3000 MH Series Transmission Cross Section
