Allison Transmission Motorhome Series Owner's Manual

7
ROTATING CLUTCH MODULE C1 CLUTCH C2 CLUTCH TURBINE SHAFT
CONTROL MODULE ELECTRO-HYDRAULIC CONTROLS
P1 MODULE P2 MODULE
MAIN HOUSING MODULE MAIN HOUSING C3 CLUTCH C4 CLUTCH C5 CLUTCH
MAIN SHAFT MODULE MAIN SHAFT P2 SUN P3 SUN
REAR COVER MODULE OUTPUT SHAFT P3 MODULE C5 PISTON
V06343
CONVERTER MODULE
TURBINE
PUMP
STATOR
LOCKUP
CLUTCH/DAMPER
CONVERTER HOUSING MODULE
CONVERTER HOUSING
FRONT SUPPORT/OIL PUMP MODULE
FRONT SUPPORT
OIL PUMP
Typical 4000 MH Series Transmission Cross Section
