P+JAssem Version 1.1 3 1 December 2017
8.Tuning Machines X 4
9. Output Jack (on control plate, or pickguard)
10.Strap Pins (Pin, Screw, Washer) X 2
11.String Retainer
12.Pickguard/Control plate mounting Screws
13.Allen Wenches
If anything is missing or not correct, please contact our customer service department ASAP!
(www.alloyguitars.com, 888-214-8314, help@alloyguitars.com)
Figure 2 Body (J-style body shown) Figure 3 Neck
Figure 4 J-style Control Plate and Pickups Figure 5 J-style Pickguard
