Operating Instructions and Parts Manual
High Pressure Abrasive Blast Cabinet
Description
A Perfectly combined traditional abrasive blast cabinet with pressure blaster tank
Provides deeper penetration of abrasive and higher strip rates
Large front opening and work space, accommodates various kinds of work pieces
Foot pedal valve control allows flexible operation and reduces hand fatigue
Large viewing window, L.E.D. lighting and two dust collector provide greater visibility
Specifications and Dimensions
Nozzle Size: 4MM
Nozzle Material: Boron carbide
Maximum Air pressure: 110PSI
CFM: 25 @ 80 PSI with 4MM nozzle
Overall Dimensions: 70”W x 79.5H x 57.8D (95”H with door open)
Working Pressure: 60~110PSI
Abrasive hose: 1”OD – ½” ID
Abrasive grit size: 40-120 with 4MM nozzle
Tank Capacity: 5.4 Gallon
Tank Dimensions: 12.1” x 14.5”
Motor Rating: 110~120V, 60 Hz, 1100W（Each SINGLE MOTOR）
Work Light: LED light 3 Bulbs,20W EACH
Air supply: 1/2” ID air line minimum
