28
42000
Operating Instructions and Parts Manual
High Pressure Abrasive Blast Cabinet
Item No.
Part No.
Description
Qty.
12-1
4201201
Tank
1
12-2
4201202
Gate Valve
1
12-3
40213
G1/2″Straight Coupling
1
12-4
4201204
Abrasive Tee Joint
1
12-5
42075
16mm Air Hose
1
12-6
4201206
G1/2″ Tee Joint
1
12-7
4201207
G1/4″Y Joint
1
12-8
4201208
Safety Valve
1
12-9
4201209
Cylinder Block
1
12-10
Bolt M8*30
8
12-11
Service Port Cover
1
12-12
4201212
Service Port Gasket
1
12-13
4201213
Sealing Head
1
12-14
Included with 4201213
Fixed-tube
1
12-15
4201215
O-Ring
1
12-16
Inlet Welding Assembly
1
12-17
4201217
Closure Gasket
1
12-18
Bolt M8*25
4
12-19
4201219
Rubber Gasket
1
12-20/C1
4201109
G1/4″Straight Coupling
1
12-21
4201106
G1/2″-16 Straight Coupling
3
12-C2
420122
G1/8″Straight Coupling
1
12-C3
420122
G1/8″Straight Coupling
1
