Page 2 • IL498 Tek-VIEW
®
Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved.
Figure 1—VM320B Entrance Panel Housing Chart
1. Additional panel required for PO202I Postal Option.
2. Wall opening height is 17-1/4" (438 mm) for OH190 series housings.
3. For systems larger than 160 buttons, contact factory.
4. See Figure 2 for wall opening width (*A).
5. Use TekTone
®
's “AM” series combination button/directory panels for the
smallest applications.
Figure 2—OH-Series Entrance Panel Housing
Figure 3—IH357 Ring, IH358 Box and VM104 Mounting Plate
NUMBER OF BUTTONS NUMBER & TYPE OF PANELS WALL OPENING
PER
SYSTEM DIRECTORY CAMERA BUTTON HOUSING WIDTH (*A)
1 - 60 1 1 1 OH193 12-1/2" (317 mm)
64 - 84 2 1 1 OH194 16-1/2" (419 mm)
88 - 120 2 1 2 OH195 20-1/2" (521 mm)
124 - 160 3 1 2 OH196 24-1/2" (622 mm)
16-7/8"
429mm
3-1/2"
89mm
A (-3/8")
17-1/4"
438mm
-9.5mm
66"
1.7m
17-1/4"
438mm
A
A
Finished Floor
