Alpha CD13R, 18R, 24R - Short Parts List
11 SHORT PARTS LIST
Reference
Burner - CD13R/18R
Burner - CD24R
Main injector 5.1 mm (CD13R/18R)
Main injector 5.25 mm (CD24R)
Primary heat exchanger - CD13R/18R
Primary heat exchanger - CD24R
Gas valve - Dungs
Fan assembly
PCB
Flue thermostat (102°C)
Ignition generator
Transformer
Temperature sensor
Fuse F2A
PCB fuse F315mA
Overheat thermostat (90°C)
Ignition electrode and lead
Ignition electrode
Flame sensing electrode and lead
Combustion chamber insulation panel front
Condensate trap
Description
British Gas GC No.
H28-392
E94-407
H28-393
H28-394
H28-395
H28-396
H28-397
E94-413
E94-414
E94-415
E76-317
E76-378
E96-571
H28-398
E94-417
E94-418
E96-572
E94-420
Alpha Pt. No.
1.021877
1.013172
1.022472
1.022709
1.021521
1.019725
1.018808
1.021206
1.027267
1.023071
1.018162
1.012477
1.015970
1.6098
1.013931
1.010952
3.013626
1.016779
1.019293
1.014732
3.016875
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
Fig. 26
Fig. 26
Fig. 2
Fig.2
Fig. 29
Fig. 29
Fig. 24
Fig. 25
Fig. 28
Fig. 27
Fig. 27
Fig. 27
Figs. 2 and 27
Fig. 20
Fig. 28
Fig. 27
Fig. 27
Fig. 26
Fig. 27
Fig. 26
Fig. 25
