2. General Description
2.1 Overview
The Alpha Micro are designed with NEMA 3R rated enclosures for outdoor applications. Three different enclo-
sures exist: (1) standard Micro, (2) Micro XL, and (3) Micro XL3. Each of these enclosures can be configured with
the 300 W or the 1000 W power module (E-Module). Although the end system configuration may look different,
the front panel connectors and circuit breakers along with the input and output terminal blocks are functionally
the same. They all operate in the same way unless otherwise stated in this manual.
Alpha Micro
1 battery tray
Alpha Micro XL3
4 battery trays
Alpha Micro XL
2 battery trays
Figure 1 — Alpha Micro Family
