BRACKET ASSEMBLY HALTERMONTAGE SUPPORT DE MONTAGE8.
SOCKET ASSEMBLY SOCKELMONTAGE INSTALLATION DU SOCLE
AMD TR4/sTRX4/sWRX8/SP3
EN DE FR
Select the appropriate holder and plug it
together. Both holders are mounted identically.
Entsprechende Halterahmen wählen und
zusammenstecken. Beide Halterungen
werden identisch montiert.
Sélectionnez le cadre de maintien
correspondant et emboîtez-le. Les deux
supports sont montés de manière identique.
EN DE FR
The TR4/sTRX4/sWRX8/SP3 Screw the bolt
into the socket, place the cooler with the
bracket on the socket and x it with pressure
springs and nuts.
Die TR4/sTRX4/sWRX8/SP3 Bolzen in den
Sockel eindrehen. Den Kühler mit der
Halterung auf den Sockel setzen und mit
den Druckfedern und Muttern xieren.
Vissez les boulons TR4/sTRX4/sWRX8/SP3
dans le socle. Placez le refroidisseur avec le
support sur le socle et xez-le avec les
ressorts de compression et les écrous.
4x TR4/sTRX4/sWRX8/
SP3 Bolzen/Bolt
4x M4 Knurled nuts/
Rändelmuttern/Ècrous moletès
Do not use tools, only tighten up hand-tight!
Kein Werkzeug benutzen, nur handfest
anziehen!
Ne pas utiliser d’outils, ne serrez que la main!
4x Pressure spring/Druckfeder/
Ressorts

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alphacool Eisbaer Pro Series and is the answer not in the manual?

Alphacool Eisbaer Pro Series Specifications

General IconGeneral
Pump Speed2500 rpm
ExpandableYes
Hose Length400mm
Connector SizeG1/4"
Warranty2 years
Fan Size120 mm
CPU Socket CompatibilityIntel LGA 115x, 1200, 2011, 2011-3, 2066; AMD AM4, AM3(+), AM2(+), FM2(+), FM1
Radiator Size280 mm
Fan Speed500 - 2000 RPM
Pump Noise Level20 dB(A)
