Drawing⑧
1.Put the small frame on the big roof, then put the middle board to
the neck of the frame, lock them by screw CT-M5*50.
2.Please attention, the contact surface of the small frame and middle
board should be flat.
The neck location
keep the contact surface flat
big roof 6
Big roof 5
Big roof 4
Big roof 2
Big roof 3
Big roof 1
Screw CT-M5*50
