3DE-7886R
<LW RADIO >
Intermediate Frequency o.....ccccceecccceceeeeseeesceseseeeecesecsesseseesseecasseeaseasesenecsesaeteseeseseetenssdssaseeransasreaerenineneseesy 450kHz
Frequency RANG@ .ceeeecccseeesecssesesessesessssesscnsesessssecsscassecscensceeansesenscseetseetenecseiseesssssssssasenseiasseasaeneees 153 -~281kHz
Usable Sensitivity (20dB S/N, at 216KHZ) oo. eee ccc cecscesetetecseenenecseeseeeteneeneneesseeeetenereeinecesesisneseresssseraeresentes 42dB
S/N Ratio (at 216KHZ) oo... cececcseccccssceeeeesceecenecceeecneeeseseeeeesuesussscausecsasseeseseeseseneeeseesaseeeenaseatarsaereeeasesesacersacenaeas 42dB
Distortion (€t 21GKHZ) ......ccssssessscscesessscseseesescasnconescecesssaesseecesersucsusuessenesssececaenessenenasseseseeneneeesreeeeeeasensseteteaeaneas 1.5%
Frequency Response (Ref. 400HZ, at 216KHZ) oo... eeecceceteesceeesseseeseeeceeceeeaeeseaecaeeesssieeaasnsnassaseges 100Hz : -344dB
4kHz : -12+6, -12dB
<GENERAL > ;
Power Supply ...c..cscccsssesssceseceesssctssecencesencsscsssesscsessnvassesacsasuesseusssscseeereessesessessssssesasoeansessoesssesseeescasoeseeaiens DC14.4V
Power Output (T.H.D. 10%) AMmpedance occ cecccceesseeceecscsceeceesereseneeecnentseecaesasneetanaseesnenseseesieeeeeas 14W/ch/4ohm
PreOuUtOUVIMPSGANCO.. cs. qcseceeccsdsebdesdinbescusevescs chlevasdtisiesahedecs asearsceutoswevsdivsatlaece ania aaataaeatiaet eens: 1.7V/10Kohm
SOMICONGUCLOTS “ccz..s2.sisivus Seva ve seed aa hevel getenteaseeweelecs deeedandanadtbens 28IC's, 52Transistors, 25Diodes, 14Zener Diodes
Dimensions: (W XH XD). ccsccdiseecteteideesteccteeute cs ovascsesasessastabesessavencendvrnsettonenssest¥aed betters Chassis : 178 X50 X153mm
Nose : 170 X46 X18mm
Wight, <cteuekec2 25 ase te Eee Ree ace nt gg Linen io stein teste teseerentear taneremereete esse 1.8kg
NOTE : Due to Continuing product improvement, specifications and designs are subject to change without notice.
