Alpine CDA-9833R - Traffic Information and Priority PTY; Traffic Info During CD;Radio Playback; Priority PTY Function

Step
Description
Connection
Signal Generator
Dial Control
Test Point /
P.W.Board
Coordinates
Adjustment
7
Noise Level
Adjustment
Figure 6
(1)
—
—
—
Set up of Adjustment Mode :
Push SOURCE/POWER +
UP at the same time.
(2)
98.1MHz,
72 --> -20dBµ
(Mod. OFF)
98.1MHz
Audio Output
(RCA)
Rotary encoder is turned and noise level
is adjustment.
(SPEC) : Noise Level : 33±10dB.
(3)
—
—
—
Cancel Adjustment Mode :
Push SOURCE/POWER +
UP at the same time.
CDA-9833R
