No. Symbol I/O Terminal Description
69 TRDT I Serial signal input terminal from DSP-IC.
70 XLAT O Data latch signal output terminal to DSP-IC.
71 RDS FIN I Status data signal input terminal from RDS u-COM.
72 CLCK I Sub-code reading clock input terminal.
73 CD F-IN I FRAME signal input terminal.
74 CD F-OUT O FRAME signal output terminal.
75 REG RESET O Reset signal output terminal to System REG.-IC.
76 RDS RESET OUT RESET control signal output terminal to RDS u-COM.
77 T-MUTE IN A-MUTE signal input terminal from RDS u-COM.
78 RDS FOUT O Data signal output terminal to RDS u-COM.
79 RDS STBY O Stand-by signal output terminal to RDS u-COM.R
80 2way/3way I 2WAY/3WAY switching signal input terminal. (H : 3way. L : 2way)
81 DOOR LED O ESC LED lighting control output terminal.
82 LIMIT SW1(OPEN) I OPEN LIMIT SW signal input terminal. (H : SW OFF, L : SW ON)
83 LIMIT SW2(CLOSE) I CLOSE LIMIT SW signal input terminal. (H : SW OFF, L : SW ON)
84 MOTOR ON O Power control signal output terminal for active NOSE Motor.
85 MOTOR FOR O Active NOSE Motor forward driving signal output terminal.
86 MOTOR REV O Active NOSE Motor backward driving signal output terminal.
87 HI-TEMP I HI-TEMP input terminal of CD mechanism.
88 DISC IN I DISC-IN detect signal input terminal of CD.
89 AUDIO I A/D DATA input terminal from AUDIO LEVEL signal.
90 NC - No connect terminal.
91 AFC I AFC input terminal.
92 NC - No connect terminal.
93 NC - No connect terminal.
94 GND I GND terminal of A/D converter.
95 NOSE DET I NOSE detect terminal.
96 VCC - Standard voltage input terminal of A/D converter.
97 VCC - Power supply input terminal of A/D converter.
98 NC - No connect terminal.
99 NC - No connect terminal.
100 NC - No connect terminal.
TMP91CP27U : IC104 (DP23S2DO)
No. Symbol I/O Terminal Description
1 VREFL - GND terminal of A/D converter.
2 NC(PULL-DOWN)
3 E2CE(PULL-DOWN)
4 NC(PULL-DOWN)
5 NC(PULL-DOWN)
6 QDATAF O Synchronous clock signal output terminal to Main u-COM.
7 /FIN I IS-BUS FRAME signal input terminal.
8 REQ I REQ signal input terminal.
9 /FOUT O IS-BUS FRAME signal output terminal.
10 NC(PULL-DOWN) - Pull-down connect terminal.
11 TXD(PF_IS) O PF-IS-BUS signal output terminal.
12 RXD(PF_IS) I PF-IS-BUS signal input terminal.
- Pull-down connect terminal.
