Connections
* When Subwoofer is OFF: Output is for Front speakers. When Subwoofer is ON: Output is for Subwoofer.
For details on how to set the Subwoofer to ON/OFF, see “Subwoofer On and Off” on page 15.
Antenna
(Blue)
(Blue/White)
ILLUMINATION
GND
BATTERY
(Green)
(Green/Black)
(White/Black)
(Grey)
(Violet/Black)
(Violet)
To iPod/iPhone
To power antenna
To amplifier
To the instrument cluster illumination
lead
Ignition Key
Battery
Speakers
Rear Left
Front Right
Rear Right
(White)
SPEAKER
RIGHT FRONT
SPEAKER
RIGHT REAR
SPEAKER
LEFT REAR
SPEAKER
LEFT FRONT
Front Left
REMOTE TURN-ON
AUDIO INTERRUPT IN
(Pink/Black)
IGNITION
(Grey/Black)
Not used
Amplifier
Front or Subwoofers*
POWER ANT
(Orange)
(Red)
(Yellow)
(Black)
Speakers
