Alpine CDE-173BT User Manual

10-EN
Initial System Start-Up
Be sure to press the RESET button when using the unit for the first time,
after changing the car battery, etc.
1 Turn off the unit power.
2 Remove the detachable front panel.
3 Press RESET with a ballpoint pen or similar pointed object.
Adjusting Volume
Turn the Rotary encoder until the desired sound is
obtained.
* The illustration is for CDE-173BT.
Listening to Radio
1 Press SOURCE to select TUNER mode.
2 Press BAND repeatedly until the desired radio band is
displayed.
F1 (FM1)  F2 (FM2)  F3 (FM3)  MW  LW  F1 (FM1)
3 Press TUNEA.ME to select the tuning mode.
r (Distance mode)  t (Local mode) 
off (Manual mode)  r
Note
• The initial mode is Distance mode.
Distance mode:
Both strong and weak stations will be automatically tuned in
(Automatic Seek Tuning).
Local mode:
Only strong stations will be automatically tuned in (Automatic
Seek Tuning).
Manual mode:
The frequency is manually tuned in steps (Manual tuning).
4 Press  or  to tune in the desired station.
In Manual mode, holding down  or  will change the
frequency continuously.
Presetting Stations Manually
1 Select the radio band and tune in a desired radio station
you wish to store in the preset memory.
2 Press and hold, for at least 2 seconds, any one of the
preset buttons (1 through 6) into which you wish to store
the station.
The selected station is stored.
The display shows the band, preset number and station
frequency memorized.
Notes
• A total of 30 stations can be stored in the preset memory (6 stations for
each band; FM1, FM2, FM3, MW and LW).
Controllable with Remote Control
This unit can be controlled with an optional Alpine remote control.
For details, consult your Alpine dealer. Point the optional remote
control transmitter at the remote-control sensor.
Connectable to Remote Control Interface Box
With an optional Alpine Steering Wheel Remote Control Interface
Box (not included), this unit is controllable from the vehicles
steering wheel controls. For details, contact your Alpine dealer.
RESET button
Remote control sensor
Radio


BAND
/ENTER

SOURCE/

TUNE/A.ME
Rotary encoder
Preset buttons
(1 through 6)
Online-store car audio and autogoods Winauto
winauto.ua

Alpine CDE-173BT Specifications

General

MP3 playback	Yes
Audio formats supported	AAC, MP3, WMA
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	20
RDS features	AF, EON, PTY, TA, TP
Product color	Black, Green, Red
Volume control	Rotary
CD changer capacity	1 discs
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	65 dB
Display type	LCD
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB ports quantity	1
Headphone connectivity	3.5mm
Key illumination color	Multi

Weight and Dimensions

Weight	1500 g
Dimensions (WxDxH)	170 x 25 x 46 mm
