Installing the microphone (CDE-
173EBT/ UTE-73EBT only)
To capture your voice during handsfree calling,
you need to install the microphone
.
Clip (not supplied)
Cautions
• It is extremely dangerous if the cord becomes
wound around the steering column or shift
lever. Be sure to keep it and other parts from
interfering with your driving operations.
• If airbags or any other shock-absorbing
equipment is in your car, contact the store
where you purchased this unit, or the car
dealer, before installation.
Note
Before attaching the double-sided tape , clean the
surface of the dashboard with a dry cloth.
Installation
Removing the protection collar and the
bracket
Before installing the unit, remove the protection
collar
and the bracket from the unit.
1 Pinch both edges of the protection collar
, then pull it out.
2 Insert both release keys until they
click, and pull down the bracket
, then
pull up the unit to separate.
Face the hook inwards.
Mounti
• Before in
both sid
2mm (
/
• For Japa
Japanes
e
1 Positio
dashb
for a t
2 Moun
attach
Notes
• If the catc
not be ins
• Make sure
properly e
