Alpine CDE-203BT User Manual

11-EN
EN
DE
FR
ES
IT
SE
NL
RU
PL
ALPINE CDE-201R 68-40368Z03-C (EN) 128x182
Connecting with a paired BLUETOOTH
device
To use a paired device, connection with this unit
is required. Some paired devices will connect
automatically.
1 Press and hold /SETUP for at least 2
seconds, rotate the control dial to select
[BLUETOOTH], then press it.
2 Rotate the control dial to select [BT IN],
then press it.
Make sure that lights up.
3 Activate the BLUETOOTH function on the
BLUETOOTH device.
4 Operate the BLUETOOTH device to
connect to this unit.
or lights up.
Icons in the display:
Lights up when handsfree calling is
available by enabling the HFP
(Handsfree Profile).
Lights up when the audio device is
playable by enabling the A2DP
(Advanced Audio Distribution Profile).
To connect the last-connected device from
this unit
Activate the BLUETOOTH function on the
BLUETOOTH device.
To connect with the audio device, press
SOURCE
to select [BT AUDIO].
To connect with the cellular phone, press
.
Note
While streaming BLUETOOTH audio, you cannot connect
from this unit to the cellular phone. Connect from the
cellular phone to this unit instead.
Tip
With BLUETOOTH signal on: when the ignition is turned
to on, this unit reconnects automatically to the last-
connected cellular phone.
To install the microphone
For details, see “Installing the microphone (CDE-
203BT/ UTE-200BT only)” (page36).
Connecting with an iPhone/iPod
(BLUETOOTH Auto Pairing)
When an iPhone/iPod with iOS5 or later installed
is connected to the USB port, the unit is paired
and connected with the iPhone/iPod
automatically.
To enable BLUETOOTH Auto Pairing, make sure
[AUTO PAIR] in [BLUETOOTH] is set to [ON] (page
22).
1 Activate the BLUETOOTH function on the
iPhone/iPod.
2 Connect an iPhone/iPod to the USB port.
Make sure that lights up on the display of
the unit.
Notes
• BLUETOOTH Auto Pairing is not possible if the unit is
already connected to two BLUETOOTH devices. In this
case, disconnect either device, then connect the
iPhone/iPod again.
• If BLUETOOTH Auto Pairing is not established, see
“Preparing a BLUETOOTH Device (CDE-203BT/ UTE-
200BT only)” (page10).
(your
ay of the
r, repeat
he
.
ode,” “PIN
on the
TH
TH
ion is
s unit
nable
for this unit
Device
).
this unit

Alpine CDE-203BT Specifications

General

DIN size	1 DIN
Output power	200 W
RDS features	AF, EON, PTY, TA, TP
Product color	Black
Ready for iPod	Yes
Volume control	Rotary
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Maximum power per channel	50 W
Display type	LCD
Display digits	14 digits
Illumination color	Blue, Green, Red
Display number of lines	1 lines
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP
USB ports quantity	1
Headphone connectivity	3.5mm
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30

Weight and Dimensions

Depth	177 mm
Width	178 mm
Height	50 mm
Weight	1200 g
