Alpine CDE-9880R User Manual

29-EN
<JAPANESE CAR>
USB memory Connection (sold separately)
Connect USB memory
Connect USB memory to USB cable.
Remove USB memory
Pull out USB memory squarely from the USB cable.
• When removing USB memory, pull it out straight.
• If sound is not output or USB memory is not recognized even when
USB memory is connected, remove USB memory once, then connect
it again.
• Change to a source other than the USB memory mode, then remove
the USB memory. If the USB memory is removed in the USB memory
mode, data may be damaged.
• Route the USB cable away from another cables, etc.
Front Frame
Screws (M5 × 8)
(Included)
This unit
Mounting Bracket
Cable (sold separately)
USB memory
(sold separately)
This unit
USB connector
This unit
USB connector
Cable (sold separately)
USB memory
(sold separately)

Alpine CDE-9880R Specifications

General

MP3 playback	Yes
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
Output power	200 W
Product color	Black
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-R, CD-RW
Equalizer bands quantity	2
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
File type	MP3, AAC, WMA
Key illumination color	Green
Number of optical discs	1 discs

Weight and Dimensions

Dimensions (WxDxH)	178 x 50 x 160 mm
