60-ES
Conexiones
REMOTE TURN-ON
IGNITION
GND
SPEAKER
RIGHT FRONT
SPEAKER
RIGHT REAR
SPEAKER
LEFT REAR
SPEAKER
LEFT FRONT
POWER ANT
ILLUMINATION
BATTERY
Amplicador
Amplicador
Amplicador
(Negro)
(Negro)
A la llave de memoria Flash o iPod/iPhone
Al amplicador
(Azul/Blanco)
Al cable de iluminación del conjunto de
instrumentos
A la antena eléctrica
(Rojo)
Llave de contacto
(Azul)
(Naranja)
(Amarillo)
Batería
Altavoces
(Verde)
Posterior izquierdo
(Verde/Negro)
(Blanco)
Frontal izquierdo
(Blanco/Negro)
(Gris/Negro)
Frontal derecho
(Gris)
(Violeta/Negro)
Posterior derecho
(Violeta)
Al reproductor de portátil, etc.
Micrófono
Posterior izquierdo
Posterior derecho
Frontal izquierdo
Frontal derecho
Subwoofers

Table of Contents

Other manuals for Alpine CDE-HD149BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alpine CDE-HD149BT and is the answer not in the manual?

Alpine CDE-HD149BT Specifications

General IconGeneral
MP3 playbackYes
Audio formats supportedAAC, MP3, WMA
AM band range530 - 1710 kHz
FM band range87.7 - 107.9 MHz
Supported radio bandsAM, FM
Preset stations quantity18
DIN size2 DIN
Output power200 W
Product colorBlack
Disc types supportedCD, CD-R, CD-RW
Audio output channels4.0 channels
Equalizer bands quantity9
Maximum power per channel50 W
Display typeLED
Display resolution256 x 64 pixels
Operating temperature (T-T)-10 - 60 °C
AUX inNo
Bluetooth version2.1+EDR
Bluetooth profilesA2DP, AVRCP, OPP, PBAP
Weight and Dimensions IconWeight and Dimensions
Weight1500 g
Dimensions (WxDxH)178 x 161 x 50 mm
