Alpine CDM-7861 - Wiring Diagram and Connections; Speaker and Component Wiring; Power, Ground, and Output Leads

16-EN
Installation and Connections
Connections
Antenna
Front right
Rear right
Speakers
Rear left
Front left
∗ When Subwoofer is set to OFF: Output is from Rear speakers.
When Subwoofer is set to ON: Output is from Subwoofer.
For details on how to set the Subwoofer to ON/OFF, see "Subwoofer On and Off" on page 5.
Battery
Ignition Key
To amplifier or equalizer
To power antenna
Amplifier
Amplifier
Rear or
Subwoofers
∗
Front Right
Front Left
CD Changer
(Sold Separately)
Speakers
Gray
SPEAKER
RIGHT
FRONT
REMOTE
TURN-ON
Red
IGNITION
Yellow
BATTERY
Black
GND
Blue/White
Gray/
Black
SPEAKER
RIGHT
REAR
Violet/
Black
Green
Violet
SPEAKER
LEFT
REAR
Green/
Black
White/
Black
SPEAKER
LEFT
FRONT
White
,
+
-
-
(
&
%
$
#
"
!
9
6
5
4
3
1
2
7
)
8
~
Blue
POWER ANT
