Usable AV/RCA Interface Cable (4-pole mini AV plug to
3-RCA)
Wiring convention of this system is as follows;
• Configuration commercially available 4-pole mini AV plugs is not
standardised.
Audio L (White)
Audio R (Red)
Ground
Video (Yellow)
(Yellow)
(Red)
(White)
Video input terminal
Audio input terminal (R, L)
