Alpine PKG-1000 - Page 27

Elect
r
o
n
ic
Pa
r
ts
List
Elect
r
o
n
ic
Pa
r
ts
List
Power Board Power Board
Parts Number
Descri
p
tion
Location Parts Number
Descri
p
tion
Location
023-17805-100 BA1-7805FP-E2 T0252-3
P3
65A-102MFA-02 POWER BOARD PCBA
POWER BOARD
023-17809-100 BA1-7809FP-E2 T0252-3 P1 046-2R7N25-00 C/C NPO 2.7nF/16V ±5% 0603 C32
44-1PLCC-044 PLCC 44PIN SMD
U2
046-2R7N25-00 C/C NPO 2.7nF/16V ±5% 0603
C33
023-74C08-100 74HC08DT SMD
X2
32-10424-1B1 0603 100nF 50V X7R
C22
023-74C14-100 74HC14DT/74HCT14
X1
32-10424-1B1 0603 100nF 50V X7R
C23
023-74C32-100 74HC32DT/74HCT32 OR SO-14
X3
32-10424-1B1 0603 100nF 50V X7R
C24
141-14M20-100 14.318Mhz/20PF/30PPM/49US/SMD
Y1
32-10424-1B1 0603 100nF 50V X7R
C25
121-200022-00 PH:2.0mm 2PIN DIP 90°
J3
32-10424-1B1 0603 100nF 50V X7R
C26
121-200062-00 PH:2.0mm 6PIN DIP 90 °
J1
32-10424-1B1 0603 100nF 50V X7R
C27
121-20010-220 PH:2.0mm 10PIN DIP 90 de
g
ree
J4
32-10424-1B1 0603 100nF 50V X7R
C28
121-200132-00 PH:2.0mm 13PIN 90°
J5
32-10424-1B1 0603 100nF 50V X7R
C29
122-254052-00 DIP 90 de
g
ree 5PIN
(
2511-05-RT
)
J8
32-10424-1B1 0603 100nF 50V X7R
C36
111-T13003-20 18.1*7.5
(
SSK-23E02-G6M
)
90 de
g
ree
S1
32-30034-1B1 0603 30
p
F 50V ±5%
C37
111-T13003-20 18.1*7.5
(
SSK-23E02-G6M
)
90 de
g
ree
S2
32-30034-1B1 0603 30
p
F 50V ±5%
C38
25-5964C-7AC SM5964C40J
U2
049-2R2U45-00 2.2U/50V 4*5.4
C9
023-M2801A-2
0
FM transmitter 88-92Mhz MDFM2-801A
D7
049-2R2U45-00 2.2U/50V 4*5.4
C10
131-010010-01 22AWG UL1007 800mm
CON1
049-2R2U45-00 2.2U/50V 4*5.4
C11
049-2R2U45-00 2.2U/50V 4*5.4
C12
049-2R2U45-00 2.2U/50V 4*5.4
C13
049-2R2U45-00 2.2U/50V 4*5.4
C14
049-010U42-00 SMD 10U/16V 4*5.4 ±20%
C15
049-010U42-00 SMD 10U/16V 4*5.4 ±20%
C16
049-010U42-00 SMD 10U/16V 4*5.4 ±20%
C35
049-010U42-00 SMD 10U/16V 4*5.4 ±20%
C1000
049-022U42-00 22U/16V 5*5.4 ±20%
C34
049-330U40-00 330U/6.3V 6.3*7.7 ±20%
(
ELNA
)
C8
049-330U41-10 330U/10V 6.3*10 Low ESR
(
ELNA
)
C7
049-330U43-10 330U/25V 8*15 Low ESR ±20%
C1
049-330U43-10 330U/25V 8*15 Low ESR ±20%
C2
049-330U43-10 330U/25V 8*15 Low ESR ±20%
C3
049-330U43-10 330U/25V 8*15 Low ESR ±20%
C4
049-330U43-10 330U/25V 8*15 Low ESR ±20%
C5
049-330U43-10 330U/25V 8*15 Low ESR ±20%
C6
35-00034-151 0603 0Ω 5%
R40
35-00034-151 0603 0Ω 5%
R41
35-10234-151 0603 1KΩ 5%
R11
35-10234-151 0603 1KΩ 5%
R33
35-22234-151 0603 2.2KΩ 5%
R12
35-22234-151 0603 2.2KΩ 5%
R13
35-22234-151 0603 2.2KΩ 5%
R14
35-22234-151 0603 2.2KΩ 5%
R15
35-22234-151 0603 2.2KΩ 5%
R36
35-22234-151 0603 2.2KΩ 5%
,
R38
35-56234-151 0603 5.6KΩ 5%
R16
35-56234-151 0603 5.6KΩ 5%
R17
35-56134-151 0603 560Ω 5%
R37
35-56134-151 0603 560Ω 5%
R39
35-10334-151 0603 10KΩ 5%
R8
35-10334-151 0603 10KΩ 5%
R9
35-47034-151 0603 47Ω 5%
R1
35-47334-151 0603 47KΩ 5%
R10
032-000K29-50 1206 0Ω±5%
R4
032-000K29-50 1206 0Ω±5%
R5
032-000K29-50 1206 0Ω±5%
R6
032-000K29-50 1206 0Ω±5%
R7
35-15134-151 0603 150Ω 5%
R18
35-15134-151 0603 150Ω 5%
R32
42-N5819-021 SMD 1N5819
D2
42-N5819-021 SMD 1N5819
D3
42-SS355-014 1SS355TE-17 SOD-323 SMD
D6
071-B160L-100 RB160L-40TE25 SMD
D1
100-SA1797-10 2SA1797 SOT-89
Q
1
43-C2412-K12 2SC2412K SMT3
(
SOT-346
)
SMD
Q
2
056-000058-10 SMD 451616-N20800A 3L COICS
FB1
056-000058-10 SMD 451616-N20800A 3L COICS
FB2
056-3R5U32-00 WBRH-3.5*6*0.8-T5
L1
052-68020-200 DIP 680uH±20% RT6852-681MDB1
CHOCK1
021-4LC02B-10 SMD EEPROM SO-8
U3
023-PT2314-10 4CH AUDIO PROCESSOR SO-28
U1
