B. Driver Board Adjust : ( input Voltage : 14±0.2V )
Test point & Value ( Tolerance ± 0.5Ω / 0.2V )
Test point
Value ( KΩ)
Test point Value ( V )
ROUT2_3 11.013 V1 8.473
ROUT3_4 11.021 V2 8.1011
ROUT4_5 11.0306 V3 6.8558
ROUT5_6 11.0396 V4 5.6396
ROUT6_7 11.0178 V5 5.0108
GOUT2_3 11.0608 V6 4.1322
GOUT3_4 11.0454 V7 3.7885
GOUT4_5 11.0576 V8 3.4567
GOUT5_6 11.0587 V9 3.0543
GOUT6_7 11.046 V10 1.8964
BOUT2_3 11.0178 V11 1.3535
BOUT3_4 11.0242 V12 1.1516
BOUT4_5 10.9854 V13 224.11mV
BOUT5_6 11.0295 V14 25.033mV
BOUT6_7 11.0263 VGH 12.996
VGL -7.610
A+12V 14.021
VCOM 2.5621
AVDD(TP200) 8.5012
EXT_5V 5.3662
IR+12V_OUT(TP600)
12.599
BIT1132V(TP601) 3.3032
VIT1675V(TP602) 2.5193
TP603 3.3585
DIMM_HIGH 3.3011
