Jeep Wrangler
PSS-24WRA V20211025 10/15
Sub Woofer/Amp Installation
1 Extract (4) T50 Torx Screws from the passenger side
seat.
3 Connect the power cable to the Positive (+) battery
terminal and route the cable down towards frame of
the vehicle.
5 Route the Positive (+) power cable through the
grommet under the carpet and pull the power cable
from under the vehicle. Note: seal the grommet
with silicone (not included) to prevent water from
entering the cabin.
2 Tilt the passenger seat towards the back to reveal
(2) connectors, disconnect and remove the seat.
4 Route the power cable following the factory harness
along the vehicle’s frame and secure using supplied
cable ties.
6 Mount the subwoofer level remote on the center
console next to the gear shifter and route the cable
to the passenger side seat. Plug 3.5mm plug into
the bass knob input of the PWE-S8.
To Next Page
