Jeep Wrangler
PSS-24WRA V20211025 12/15
1 Extract the (4) 5mm, allen head, bolts and remove
factory grills.
3 Remove gromment holding speaker wire in place
and secure speaker wire out of the way.
5 With a reciprocating air saw or preferred cutting
device, cut along the line from step 4.
Note: Be cautious when cutting not to cut thru the
topside of the sound bar.
2 Extract the (5) T20, torx, screws from the speakers
and the (4) T30, torx, screws from the port and
remove.
4 Use supplied template and mark area of each side
for soundbar cutting.
6 Fill the speaker cavities witht supplied polyfil
sheets.
Rear Soundbar Speaker Removal & Installation
