Jeep Wrangler
PSS-24WRA V20211025 8/15
Front speaker removal and installation (continued)
19 Looking up under the airbag assembly, remove
the (2) 13mm, bolts that secure the back of the
passenger side airbag.
21 Carefully unclip and pull out on the dashboard
panel enough to expose the speaker pod. Remove
the (3) Phillips, screws securing the pod and
remove.
23 Remove the grommet and factory wiring from the
speaker pods.
20 Unclip and slightly release the airbag panel, just
enough to expose the (3) Phillips, screws securing
the passenger side dash panel.
22 Remove the factory speakers from the speaker
pods.
24 Insert the factory wire into the replacement
speaker pods and pull gromment thru until it seats
into the hole.
To Next Page
