Ford F-150
FULL SIZE TRUCK 7/12
Factory unit disassembly process
1 On the passenger side of the vehicle, open the
glove box and push the side tabs towards each
other to release the glove box. Extract 3 x 8 mm
(may also be 3 x 10 mm) bolts to release the airbag.
2 Without disconnecting the airbag push it out far
enough to expose the copper plated 7 mm screw
on the left side of the airbag and extract it.
3 Remove the instrument cluster cover by extracting
2 x 7 mm screws.
4 Remove both side vent covers using a panel
remover tool.
5 Remove the radio bezel by extracting 2 x 7mm
screws from the top and 2 x 7mm screws from the
bottom.
6 Extract 8 x 7 mm screws from the factory display/
radio and remove both.
