Jeep Wrangler
WRANGLER 7/13
Factory Unit Disassembly Process
1 Remove the rubber cover from the top center
storage area and extract 1 x 7mm screw.
2 Remove the knee cover panel and extract 2 x 7mm
screws located to the right and left sides of the
steering wheel column.
3 Remove the window switch pod using a panel
removing tool and extract 1 x 7mm screw.
4 Remove the dash panel.
To Next Page
