Set Up
Instructions
(See Figure 2)
Do not insert the
AC power plug into
the wall outlet
until all
connections are
made.
The only requirement
to set up the ACS33 is
to insert the DIN
connector into the
input marked RIGHT
SPEAKER and to insert
the audio input plug
into the computer
audio output. For easy
insertion of the DIN
connector, notice that
the arrow on the
connector must face up
as shown in the
diagram.
RIGHT SPEAKER
RIGHT SPEAKER
Figure 2
ACS33 Setup Instructions
Placement of Speakers
All stereo information is heard from the
satellite speakers. The subwoofer
contains no stereo information and sound
is non-directional. As a result, the
subwoofer does not necessarily have to be
placed in any particular relationship to
the satellites. Placing the subwoofer on
the floor close to a wall or corner of a
room provides maximum bass efficiency.
The subwoofer is not magnetically
shielded and should not be placed near
video displays.
LIME
ORANGE
