SPECIFICATIONS
I
I
I
I
Type:
I
Power amplifier
I
Gain:
lnput
Sensitivity:
Power
Outout:
Frequency
Response:
lnput
Imoedance:
Load
Impedance:
Load Voltage:
Output
Impedance:
Output Noise
Level:
Controls:
Power
Requirements:
Operating
Temperature
Range:
Dimensions
Weight:
Color:
Accessories:
0.8V rms for rated output
100 watts at less than 1% THD
from 35 Hz to 20 kHz
100 watts at less than 0.5% THD
from 50 Hz to 15 kHz
+1 dB from 20 Hz to 20 kHz
-
15.000 ohms (potentiometer)
150 or 600 ohms with
1509!5A
Line Transformer
15.000 ohms with
15335A L.ine
Transformer
4,
8. 16 or 50 ohms (transformer-
isolated output)
20. 28. 40
or
70.7 volts
Typically less than 10% of load
impedance
85 dB below
rated output
1 VOLUME control, continuously
variable
1 primary power
ON.OFF switch
1 FILTER IN
-
OUT switch (rear
panel)
1201240V ac, 50160 Hz
-
20W at zero signal
180W at 33W output
290W at 100W output
-
or
-
24128V dc
-
0.2A at zero signal
5.OA at 33W output
8.5A at 100W output
Battery minus
(-)
is ground
Up to
55'~ (131°F) ambient
7"H
x
19"Wx 8.112
"
D
35 pounds,
8
ounces
ALTEC green
ALTEC
15095A Line Transformer
ALTEC
15335A Line Transformer
ALTEC 42526 Shelf Mount Cover
NOTE
I
ACCESSORIES MUST BE ORDERED
1
Figure 1.. Typical Power Output Versus Frequency for
0.5% THD and 1% THD (8
-
Ohm Load)
Figure
2.
Typical Frequency Response Characteristics
Figure 3. Typical
%
THD Versus Frequency for 100
-
Watt
Output
SEPARATELY
1
Figure
4.
Typical
%
THD Versus Wattage Output at 1000
Hz (8-Ohm Load)
