2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL
Page 19
12. Connect the CNG connector jumpers to the OEM injector
connectors and to the CNG injectors.
13. Connect OEM harness to the OEM temp/pressure sensor.
14. Connect CNG low pressure hose (once installed) to the fuel rail.
Ensure each end of the hose is labeled with a low pressure sticker.
15. Reconnect all OEM air hoses and place back the air intake hose/
tube.
LOW PRESSURE INSTALLATION
Jumper
11 12
13
14
To Next Page
